Support des processeurs Intel® Core™ / Pentium® / Celeron® de 6ème et 7ème génération pour socket LGA 1151 Support d'une mémoire DDR4-2400 (max.) DDR4 Boost avec Steel Armor : boostez les performances de la mémoire DDR4 Compatibilité à la réalité virtuelle pour une fluidité parfaite Mystic Light Sync pour personnaliser le look de sa carte et des périphériques compatibles Slot Turbo M.2 avec Steel Armor pour une grande robustesse Compatible à la technologie Intel® Optane Support des configurations multi-GPU AMD Crossfire™ avec slots PCIe Steel Armor Audio Boost pour une qualité audio réaliste Gaming LAN avec LAN Protect : connexion réseau parfaite, latence réduite au maximum Military Class 5 : composants électroniques de qualité et robustes Click BIOS 5 : un BIOS amélioré qui aide à améliorer l'expérience gaming EZ Debug LED pour facilement repérer les problèmes

https://fr.msi.com/Motherboard/H270M-MORTAR-ARCTIC.html#productFeature-section

€ 117.00
Exclusif web


En stock



MSI | Code article: 4719072498504

  • Info produit

CPU

• Supports 7th/6th Gen Intel® Core™ i3/i5/i7 processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151
* This function will be supported depend on the CPU.

Chipset

• Intel® H270 Chipset

Main Memory

• 4 x DDR4 memory slots, support up to 64GB
- 7th Gen processors support DDR4 2400/ 2133 MHz*
- 6th Gen processors support DDR4 2133 MHz*
• Dual channel memory architecture
• Supports Intel® Extreme Memory Profile (XMP)**
* Please refer to www.msi.com for more information on compatible memory.
* DDR4 memory modules can only run at maximum of 2400 MHz for 7th Gen processors and 2133 MHz for 6 th Gen processors on XMP mode.

Slots

• 2 x PCIe 3.0 x16 slots (support x16/x4 mode)
• 2 x PCIe 3.0 x1 slots

Onboard Graphics

• 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60Hz
• 1 x DisplayPort, supports a maximum resolution of 4096x2304@24Hz, 2560x1600@60Hz, 3840x2160@60Hz,1920x1200@60Hz
• 1 x HDMI™ port, supports a maximum resolution of 4096x2160@30Hz(7th CPU), 4096x2160@24Hz(6th CPU), 2560x1600@60Hz

Multi-GPU

• Supports 2-Way AMD® CrossFire™ Technology
Storage

• Intel® H270 Chipset
• 6 x SATA 6Gb/s ports*
• 1 x M.2 slot (Key M)
- Support up to PCIe 3.0 x4 and SATA 6Gb/s
- Supports 2242/ 2260 /2280/ 22110 storage devices
- Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host Card**
- Intel® Optane™ Memory Ready
• Supports Intel® Smart Response Technology for Intel Core™ processors

* The SATA1 port will be unavailable when an M.2 SATA SSD module has been installed in the M.2 slot.
** The Turbo U.2 Host Card is not included, please purchase separately.


RAID
• Intel® H270 Chipset
• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

USB

• Intel® H270 Chipset
- 8 x USB 3.1 Gen1 (SuperSpeed USB) ports (3 Type-A ports + 1 Type-C port on the back panel, 4 ports available through the internal USB connectors)
ƒ- 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)

Audio

• Realtek® ALC892 Codec
- 7.1-Channel High Definition Audio

LAN

• 1 x Intel® I219-V Gigabit LAN controller

Internal I/O Connectors

- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 6 x SATA 6Gb/s connectors
- 1 x M.2 slot
- 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 1 x 4-pin CPU fan connector
- 3 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x Serial port connector
- 1 x RGB LED connector
- 1 x TPM module connector
- 1 x TBT connector
- 1 x Chassis Intrusion connector
- 1 x Clear CMOS jumper

Back Panel I/O Ports

- 1 x PS/2 mouse & keyboard combo port
- 2 x USB 2.0 ports
- 1 x DVI-D port
- 1 x DisplayPort
- 1 x HDMI™ port
- 1 x LAN (RJ45) port
- 3 x USB 3.1 Gen1 Type-A ports
- 1 x USB 3.1 Gen1 Type-C port
- 6 x OFC audio jacks

Dimension

• 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
• M-ATX Form Factor

Mounting

• 8 mounting holes

  1. PS/2 GAMING Device Port
  2. DisplayPort
  3. Intel® Gigabit LAN Port
  4. USB 3.1 Gen1 Ports
  5. HD Audio Connectors
  6. USB GAMING Device Port
  7. DVI-D Port
  8. HDMI
  9. VR Ready USB 3.1 Gen1 Ports
  10. USB 3.1 Gen1 Type-C Ports
1. Les caractéristiques sont sujettes à certaines modifications sans préavis. Renseignez-vous auprès de votre revendeur afin de connaître les caractéristiques exactes.
